Alloy 317LMN Stainless Steel Plate for Chemical Industrial Thickness 0.4 - 30.0mm 2B NO.1 Finishing

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Alloy 317LMN Stainless Steel Plate for Chemical Industrial Thickness 0.4 - 30.0mm 2B NO.1 Finishing

Brand Name : TISCO

Model Number : 317LMN

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 3300 - 3480 USD/Ton

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Stainless Steel Sheet

Grade : 317LMN

Standard : ASTM EN JIS GB

Size : 1219*2438mm 1500*3000mm

Thickness : 0.5 - 3.0mm

Type : cold rolled

Service : cutting, surface treatment

application : auto exhaust pipe

Packing : wooden pallets

Contact Now

Alloy 317LMN Stainless Steel Plate for Chemical Industrial Thickness 0.4 - 30.0mm 2B NO.1 Finishing

Products Specification

Product Name
317LMN Stainless Steel Sheets
Material Type
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.


Grade
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
200series:201,202,202cu,204
400series:409,409L,410,420,430,431,439,440,441,444
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
Technology
Cold Rolled /Hot Rolled
Length
2000/2438/2500/3000/3048 mm
Width
1000/1219/1250/1500 mm
Thickness
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
Surface
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
Leveling: improve flatness, esp. for items with high flatness request.
Skin-Pass: improve flatness, higher brightness
Other Choices
Cutting:Laser cutting, help the customer to cut the required size
Protection
1. Inter paper available
2. PVC protecting film available
Price Item
FOB,CIF,DDU,FCA,EXW ,.etc
Quality Assurance
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent

Product information

Alloy 317LMN (UNS S31726) is an austenitic chromium-nickel-molybdenum stainless steel with corrosion resistance superior to 316L and 317L. The higher molybdenum content, combined with an addition of nitrogen, provides the alloy with its enhanced corrosion resistance, especially in acidic chloride containing service. The combination of molybdenum and nitrogen also improves the alloys resistance to pitting and crevice corrosion.

The nitrogen content of Alloy 317LMN acts as a strengthening agent giving it a higher yield strength than 317L .Alloy 317LMN is also a low carbon grade which enables it to be used in the as-welded condition free from chromium carbide precipitation on the grain boundaries.

Alloy 317LMN is non-magnetic in the annealed condition. It cannot be hardened by heat treatment, only by cold working. The alloy can be easily welded and processed by standard shop fabrication practices.

Technical data

Stainless Steel SA 240 Gr 317L Composition

SS C Mn Si P S Cr Mo Ni Fe
A240 317L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 18.00 - 20.00 3.00 - 4.00 11.00 - 15.00 57.89 min


Stainless Steel 317L Properties

Melting Range Density Tensile Strength (PSI/MPa) Yield Strength (0.2%Offset) (PSI/MPa) Elongation %
1400 °C (2550 °F) 7.9 g/cm3 Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %


FAQ
Q:Are you trading company or manufacturer?
A:We are a trading company with more than 15 years experience in steel export business,have the long term cooperation with big mills in China.
Q:Will you delivery the goods on time?
A:Yes,we promise to provide best quality products and delivery on time.Honesty is our company's tenet.
Q:Do you provide samples?is it free or extra?
A:The sample could can provide for customer with free,but the courier freight will be covered by customer account.
Q:Do you accept the third party inspection?
A:Yes absolutely we accept.
Q:What are your main products?
A:Carbon steel,alloy steel,stainless steel plate/coil,pipe and fittings,sections etc.
Q:Can you accept the order of customzied?
A:Yes,we assure.
